Samsung 55” UD55E Series

Display

• Diagonal Size 55"
• Panel Type D-LED DID
• Resolution 1920 x 1080
• Pixel Pitch (HxV) 0.63mm(H) x 0.63mm(V)
• Active Display Size (HxV) 1209.6 x 680.4mm
• Contrast Ratio 4000:1
• Viewing Angle (H/V) 178/178
• Response Time 8 ms
• Display Color 8 bit - 16.7M
• Color Gamut 72 %
• H-Scanning Frequency 30kHz ~ 81kHz
• Maximum Pixel Frequency 148.5MHz
• V-Scanning Frequency 48Hz ~ 75Hz
• Brightness 500 cd/m2
• Dynamic Contrast Ratio 10,000:1

Connectivity

• RGB In Analog D-SUB, DVI-D, Display Port 1.2
• RGB Out DP1.2(Loop-out)
• Audio In Stereo Mini Jack
• Audio Out Stereo Mini Jack
• Video In HDMI1,HDMI2

Set Dimension (WxHxD)

• Set Dimension (WxHxD) 1213.5 x 684.3 x 96.6 mm
• Package Dimension (HxWxD) 1355 x 809 x 320 mm

Weight

• Net Weight 21.5 kg
• Package Weight 29 kg
